Functions & Features
- Display: LCD with LED backlight .The brightness and the contrast of the LCD is adjustable.
- Display contents: thickness value, coupling condition, power state, CAL calibration state, sound velocity.
- Able to measure the ultrasonic velocity in turn if the thickness value is known in order to improve the measurement precision.
- Zero adjustment: auto returning to zero when you press the key after the probe is put on the specimen.
- Simply and easily operated.
- Nonlinear correction, automatic compensation, in order to improve the measurement accuracy.
- The test block of measuring sound velocity of known thickness.
- Battery information indicates the rest capacity of the battery,Auto sleep and auto power off function to conserve battery life.
- Optional software to process the memory data on the PC.
- Alarm function: setting the measurement limit and alarming for the results beyond the limit.
Measuring Material
- Adapted to measure the thickness of good conductor for ultrasonic, such as metal(steel, cast iron, aluminum, copper), plastic, ceramic, glass, glass fiber and so on.
Specifications
| Model | 320 | 321 | 322 | 330 | 331 | 332 |
| Measuring range(mm) | 0.7~300 | 0.7~300 | 0.7~300 | 0.7~300 | 0.7~300 | 0.7~300 |
| Resolution(mm) | 0.1 | 0.1 | 0.01 | 0.1 | 0.1 | 0.01 |
| Accuracy(mm) | ±(0.5%H+0.04)mm,H is thickness | |||||
| Velocity range(m/s) | 5920 | 1000~9999 | 1000~9999 | 5920 | 1000~9999 | 1000~9999 |
| Velocity measurement | Yes | Yes | Yes | Yes | Yes | Yes |
| Storage | No | No | 2000 Groups | No | No | 2000 Groups |
| Shell | Plastic | Plastic | Plastic | Metal | Metal | Metal |
| Operating temperature | -10℃~60℃ | -10℃~60℃ | -10℃~60℃ | -10℃~60℃ | -10℃~60℃ | -10℃~60℃ |
| Dampness | 20%~90% | 20%~90% | 20%~90% | 20%~90% | 20%~90% | 20%~90% |
| Dimensions | 130×70×25mm | 130×70×25mm | 130×70×25mm | 130×70×25mm | 130×70×25mm | 130×70×25mm |
| Power supply | 2 AAA alkaline batteries | 2 AAA alkaline batteries | 2 AAA alkaline batteries | 2 AAA alkaline batteries | 2 AAA alkaline batteries | 2 AAA alkaline batteries |
| Weight | 200g | 200g | 200g | 420g | 420g | 420g |
