Functions & Features
- Two methods of power off: Manual & Automatically.
- Limit settings: alarm if one of the measurement data is beyond of the limits.
- Deleting function: You can delete one of the doubtful data and you can also delete all of data in the memory to prepare for new measurement.
- Saving function: capable of 500 sets of measurement value.
- Five statistical data: Mean Value, Maximum Value, Minimum Value, Measurement, Standard Deviation.
Measuring Material
- Non magnetic coatings on magnetic substrates (such as aluminum, chromium, copper, zinc, tin, rubber, paint on the steel, iron, alloy and magnetic steel) . (Fe)
Non conductive coating on non magnetic metal (such as rubber, plastic, paint, oxide on aluminum, copper, zinc, tin) . (NFe)
Specifications
Model | 210 | 211 | 220 | 221 | 222 | 232 |
Operating principle | Magnetic induction(Fe) | Eddy Current (NFe) | Magnetic induction(Fe) | Eddy Current (NFe) | Fe and NFe | Fe and NFe |
Measuring range (µm) | 0~1250μm | 0~1250μm | 0~1250μm | 0~1250μm | 0~1250μm | 0~1250μm |
Probe | Settled | Settled | Changeable | Changeable | Changeable | Changeable |
Shell | Plastic | Plastic | Plastic | Plastic | Plastic | Metal |
Accuracy | ±[(1~3%)H+1] | ±[(1~3%)H+1] | ±[(1~3%)H+1] | ±[(1~3%)H+1] | ±[(1~3%)H+1] | ±[(1~3%)H+1] |
Low range resolution | 0.1μm | 0.1μm | 0.1μm | 0.1μm | 0.1μm | 0.1μm |
Min curvature of the min area (mm) | Convex1.5 Concave9 | Convex1.5 Concave9 | Convex1.5 Concave9 | Convex1.5 Concave9 | Convex1.5 Concave9 | Convex1.5 Concave9 |
Diameter of the min area | Φ7mm | Φ7mm | Φ7mm | Φ7mm | Φ7mm | Φ7mm |
Critical thickness of substrate | 0.5mm | 0.5mm | 0.5mm | 0.5mm | 0.5mm | 0.5mm |
Memory | 500 Groups | 500 Groups | 500 Groups | 500 Groups | 500 Groups | 500 Groups |
Dimensions | 115×70×30mm | 115×70×30mm | 115×70×30mm | 115×70×30mm | 115×70×30mm | 115×70×30mm |
Power supply | AAA | AAA | AAA | AAA | AAA | AAA |
