- Double-fixing four-slot design, double developing and fixing, can make the image fully visible and transparent,

and get rid of pseudo defects.

- The waterless circulation system can be operated at the inspection site without being affected by water sources.

- The bright room delivery system (optional) makes your operation easier.

- Infrared sensing control system and self-contained controllable red light to avoid artificial scratches during film

entry.

- The professional prototype air duct drying system makes the film evenly exposed on both sides of the film,

so that the film does not produce water marks.

- Microcomputer program control, stable and reliable performance.

Technical Specifications

Film SizeMinimum 60×100mm/Maximum 430×∞
Developing Time6-14min.(1 min step adjusting)
Developing Amount25-60PCS/hr(14×17inch)/110-280PCS/hr(80×300mm)
Power SupplyAC 220V/50Hz/15A
CapacityDeveloper 13L / Fixer 13L+13L / Water 15L
Developing Temperature20-40°C
Fixing Temperature20-40°C
Drying Temperature20-70°C
Developer and Fixer ReplenishingAutomatic/Manual Replenishing(50-500ml/m2)
Water Consumption2L/min
Water temperatureNormal
Dimension1350×720×1200mm
Net Weight125Kg
