- Microcomputer infrared control into the film feeding system, stable and reliable.

- Double sink to ensure clear images.

- The independent tail-crossing bridge design prevents the splash of liquid medicine and has

no film jamming.

- Adjustable roller arrangement ensures no indentation.

- DuPont high-strength roller developing, fixing, washing, independent circulation system.

- Reliable transfer of various film built-in red light, magnetic control dimming, check film

feed status.

- The professional prototype air duct ensures that the film is evenly dried.

- Start the design at regular intervals to prevent crystallization.

- International brand speed control system.

Technical Specifications

Film Size
Minimum 80×100mm/Maximum 430×∞
Developing Time6-14min.(1 min step adjusting)
Developing Amount25-55PCS/hr(14×17inch)/95-220PCS/hr(80×300mm)
Power SupplyAC 220V/50Hz/10A
CapacityDeveloper 13L / Fixer 13L / Water 13L
Developing Temperature20-40°C
Fixing Temperature20-40°C
Drying Temperature20-70°C
Developer and Fixer ReplenishingAutomatic/Manual Replenishing(50-500ml/m2)
Water Consumption2L/min
Water temperatureNormal
Dimension1050×720×1230mm
Net Weight95Kg
