- DuPont high-strength densely packed rollers ensure safe transfer of any size film.

- The specially designed sink can greatly enhance the fixing force for a large number of film rinses.

- Process: developing, stop washing, fixing, little washing, washing, drying.

- Combine the functions in one, you can view its display, fixing temperature, drying temperature, replenishment

amount, film running status with a single touch.

- Easy to use, at a glance. Four sets of infrared sensors High-power radiator development / fixing separate

purification of international brand electronic speed control motor system, stable, durable, quality certified,

suitable for large-volume punching.

Technical Specifications

Film SizeMinimum 80×100mm/Maximum 430×∞
Developing Time6-14min.(1 min step adjusting)
Developing Amount18-42PCS/hr(14×17inch)/88-210PCS/hr(80×300mm)
Power SupplyAC 220V/50Hz/8.8A
CapacityDeveloper 12.5L / Fixer 12.5L / Water 12.5L
Developing Temperature20-40°C
Fixing Temperature20-40°C
Drying Temperature20-70°C
Developer and Fixer ReplenishingAutomatic/Manual Replenishing(50-500ml/m2)
Water Consumption2L/min
Water temperatureNormal
Dimension1050×720×1230mm
Net Weight85Kg
