- DuPont materials high-strength densely arranged roller shafts, adjustable roller shaft spacing positioning and

non-positioning devices to avoid scratches, indentations and other false defects caused by various reasons, to

ensure the safe transfer of any size film.

- Four-channel infrared sensor with built-in controllable red light to check the film being fed, preventing film

scratches and deviations.

- The specially designed sink can greatly enhance the fixing force for a large number of film washing.

- Process: developing, washing, fixing, little washing, washing, drying.

- With all the functions in one, you can check its display and fixing temperature, drying temperature,

replenishment amount and film running status with one touch. Easy to use, at a glance.

Technical Specifications

Film SizeMinimum 60×100mm/Maximum 430×2000mm
Developing Time6-14min.(1 min step adjusting)
Developing Amount8-42PCS/hr(14×17inch)/88-210PCS/hr(80×300mm)
Power SupplyAC 220V/50Hz/10A
CapacityDeveloper 12.5L / Fixer 12.5L / Water 12.5L
Developing Temperature20-40°C
Fixing Temperature20-40°C
Drying Temperature20-70°C
Developer and Fixer ReplenishingAutomatic/Manual Replenishing(50-500ml/m2)
Water Consumption2L/min
Water temperatureNormal
Dimension1050×720×1230mm
Net Weight85Kg
